Required connection to machine: 3rd control circuit
Recommended: Notch for 3rd control circuit
Connections BSFH20 / BSFH40:
1 hose (milling wheel drive system)
1 hose (return)
Required connection to wheel loader:
3rd control circuit
Unpressurized return in the front
Connections BSFH42:
1 hose (milling wheel drive system)
1 hose (return)
Required connection to wheel loader:
High Flow
Unpressurized return in the front
Connections BSFH20S / BSFH40S:
1 hose (milling wheel drive system)
1 hose (return)
1 electrical connection
Required connection to wheel loader:
3rd control circuit
Unpressurized return in the front
Electrical connection in front
Connections BSFH42S:
1 hose (milling wheel drive system)
1 hose (return)
1 electrical connection
Required connection to wheel loader:
High Flow
Unpressurized return in the front
Electrical connection in front
Notice: Not approved for public traffic! National regulations must be observed!
