Uzay Makina UMSY 900-1300 SP Wide-Heavy Cut Hydraulic Bandsaw Machine (UMSY 900-1300 SP)

Heavy-duty, strong saw benches with columns. These models are especially designed and produced for inconel, titanium, high-strength, difficult-to-cut materials. These models have higher engine power and have a hydraulic cradle-type clamp system as standard. It is held from both the front and the back of the cut with the tool. This feature ensures that the remaining part length is minimal. It is especially recommended in steel and metal service centers, forging workshops and businesses where the cutting of tool steels is common. The optional laser line is recommended.

90°	RECTANGLE	SQUARE	ROUND
	900×1300	900	900



Main Engine	7.5 kW 1500 rpm
Cooling Engine	0.37 kW 3000 rpm
Hydraulic Motor	1.5 kW 1500 rpm
Drive Motor	1.1 kW
Chip Conveyor	0.18 kW 1000 rpm
Chip Brush	0.09 kW 3000 rpm
Tape Measure	10000x67x1.6 mm
Loading Weight	5600 kg
Feeding Height	650mm
Working Dimensions	4900x1800x3100 mm

• hydraulic descent system
• Inverter lane speed control
• hydraulic double vise
• Hydraulic belt tensioning system
• Ribbon break plug
• coolant pump
• Cutting height adjustment
• Linear girl column system
• Hydraulic shear descent speed control
• Fixed control panel
• Hydraulic linear guide strip guide arm
• Motorized material conveyor rollers

UMS 900-1300 SP CATALOG

UMSY 900-1300 SP
