Uzay Makina UMSO 350 Automated Production Full Automatic Bandsaw Machine (UMSO 350)

They are fully automatic models with articulation. The material application process should be done with roller drivers in the vices. The length is adjusted with a switch support system. It is a model recommended for productions with straight and numbered cuts.

90°	RECTANGLE	SQUARE	ROUND
	320×450	320	350



Main Engine	2.2 kW 1500 rpm
Cooling Engine	0.09 kW 3000 rpm
Hydraulic Motor	0.25 kW 1500 rpm
Drive Motor	0.25 kW 1500 rpm
Chip Conveyor	0.18 kW 1000 rpm
Cutting Speed	20 - 100 m/min
Cutting Speed	20-100 m/min
Tape Measure	4320x34x1.1mm
Loading Weight	850 kg
Feeding Height	650mm
Working Dimensions	2500x1000x1950 mm

• Inverter lane speed control
• Hido-mechanical belt tensioning
• Ribbon break plug
• coolant pump
• 1200 mm material stand
• hydraulic vise
• Cutting height adjustment
• Roller clamp system
• Possibility of programming the number of cuts
• Movable control panel
• Mechanical material height stop adjustment
• Hydraulic shear descent speed control
