Trelawny SC1 Pneumatic Single Head Scabbler

Trelawny SC1 Pneumatic Single Head Scabbler

Trelawny SC1 Pneumatic Single Head Scabbler

Trelawny SC1 Pneumatic Single Head Scabbler

Trelawny SC1 Pneumatic Single Head Scabbler

Trelawny SC1 Pneumatic Single Head Scabbler (SC1)

Brand : Trelawny

Stock Amount : 20

Delivery Time Stock

Shipment Place Turkiye

Payment Terms % 100 T/T On Order Confirmation

Made In United Kingdom

Min. Order Qty. 20 Pcs.

Warranty1 year

Add to Favorites

Add to My Wish List

Notify me when the price goes down

Notify me when it is in stock

The SC1 is the most powerful single-head scabbler for heavy-duty applications. The new cap design and replaceable cylinder sleeve make servicing even simpler. Vibro-Lo™ low vibration system fitted as standard.

Removal of laitance
Roughening and exposing aggregate
Preparing joints and cracks
Removing existing coatings
Reduction and levelling

Single replaceable tough carbide tipped piston for fast production and long service life
Sturdy top cap design for easy maintenance and reassembly
Heavy duty cast body to suit the heaviest of applications
Trelawny Vibro-Lo™ vibration reduction system for operator safety

Part Number	151.6171
Weight (kg)	2.85
Length (mm)	520.00
Width (mm)	N/A
Working Height (mm)	130
Blows Per Min (BPM)	2800
Air Consumption (lps – cfm)	5.6 – 12
Air Pressure	6.2 bar (90 psi)
Air Inlet	3/8″ NPT (c/w 3/8″ BSP Adapter)
Noise Level (db (A))	98.5
Vibration Level – Concrete (trigger hand) Bush Primary	9.4 m/s² (K= 1.13m/s² )
Vibration Level – Concrete Bush Secondary	14.1 m/s² (K=2.22m/s² )
Piston Diamter (mm)	27.0
Piston Length (mm)	111.75
Piston Stroke (mm)	26.5

Part Number	151.6170
Weight (kg)	2.85
Length (mm)	520mm
Width (mm)	N/A
Working Height (mm)	N/A
Blows Per Min (BPM)	2800
Air Consumption (lps – cfm)	5.6 lps (12cfm)
Air Pressure	6.2 bar (90 psi)
Air Inlet	3/8″ NPT (c/w 3/8″ BSP Adapter)
Noise Level (db (A))	98.5
Vibration Level – Concrete (trigger hand) Cruciform Primary	9.15 m/s² (K=2.95m/s² )
Vibration Level – Concrete Cruciform Secondary	13/7 m/s² (K=1.5m/s² )
Piston Diamter (mm)	27.5
Piston Length (mm)	111.75
Piston Stroke (mm)	26.5

Image	Part Number	Description
	612.6000	Single Piece Cruciform Piston Flatter surface profile, ideal for fast reduction of material
	612.6010	Single Piece Bush Piston Rough pitted profile, ideal for application of fresh concrete or coatings
	446.1650	SC1 Service Kit (Cruciform Piston) Consists of: – Valve Cap O’Ring, Valve Spring, Valve Stem, Valve Seat O’Ring, Throttle Lever, Spring Pin (1 each) – Cylinder Sleeve, Cruciform Piston, Nylon Pad, Cylinder O’Ring (1 each)
	446.1655	SC1 Service Kit (Bush Piston) Consists of: – Valve Cap O’Ring, Valve Spring, Valve Stem, Valve Seat O’Ring, Throttle Lever, Spring Pin (1 each) – Cylinder Sleeve, Bush Piston, Nylon Pad, Cylinder O’Ring (1 each)

Image	Part Number	Description
	815.5550	Whip Check
	859.1555	½’’ BSP inline lubricator
	421.3452	Whip Hose Consists of air hose 3/8’’ BSP claw – 2m
	458.1555	Whip Hose & Oiler Assembly Consists of whip hose, whip check and ½ lubricator
