Features: The system adopts Windows CE controller Six-axis programmable control, XYZ+ABC (can be replaced by XYZ+ABW or XYZ+ACW) ATC system and A, B, C axis and spindle tilt option are available to increase machine functionally Column movable master by linear slideway on X/Y/Z Automatic lubrication USB port Use a 15-inch LCD touch screen, mouse, and standard keyboard Presented in a dialog window with 3D stereo graphic description Machining path and graphic display Close-loop and feedback circuit design of 0.001mm resolution numerical linear scale is adopted on the 3 axis of the machine. Such design could get precise position setting, and increase the machining precision and efficiency of ORBIT-CUT Dialogue programming editor that provides variety of hole enlargement modes (including function of edge search, center search, reference point search) Automatic multi-step machining is available Automatic home search function ARC automatic arcing adjustment Automatic center search and offset which could search the center and the deepest point of the hole Movement of axis linear (3 axis), arc (2 axis), spiral (3 axis) and offset Switch function: Language switch (Chinese/English) and unit system switch (Metric/Inch) Single side sparking of 3 axis and 6 directions (plane rotation) Automatic programming edition function: According to the material, area, initial current and wear rate do proper adjustment
