Prompt 26'' series 2640/2660/2680/26120/26160ENC CNC Lathe Flat Bed (26" series 2640/2660/2680/26120/26160ENC )

Brand : Prompt

Stock Amount : 0

Est. Delivery Time60-75 Days After Order

Shipment Place Turkiye

Payment Terms% 30 T/T On Order Confirmation, % 70 T/T Before Shipment

Made InChina

Min. Order Qty.1 Pcs.

Warranty1 Year

Add to Favorites

Add to My Wish List

Notify me when the price goes down

Notify me when it is in stock

Lathes

Slant-Bed CNC Lathe

MODEL	Unit	26" series 2640/2660/2680/26120/26160ENC
Swing over bed	mm(inch)	660 (26)
Distance between center	mm(inch)	1000/1500/2000/3000/4000 (40/60/80/118/160)
Max. cross slide travel	mm(inch)	405 (16)
Max longitudinal travel	mm(inch)	1000/1500/2000/3000/4000 (40/60/80/118/160)
Swing over cross slide	mm(inch)	440 (17)
Swing over gap	mm(inch)	840 (33)
Spindle bore	mm(inch)	105 (4) / 155 (6)
Spindle nose		D1-11 (105mm,4") / A2-11 (155mm,6")
Spindle nose bush		MT#7
Spindle speed number	steps	.-
Spindle speed range	rpm	20-1500 (105mm,4") / 20-1200 (155mm,6")
Tailstock travel	mm(inch)	250 (10)
Tailstock diameter	mm(inch)	105 (4)
Tailstock taper		MT#5
Width of bed	mm(inch)	450 (17)
Cross slide (x) ball screw		Ø32 x P5
Cross slide (x) servo motor	Nm	6.3
Longitudinal (z) ball screw		Ø50 x P10
Longitudinal (z) servo motor	Nm	16.5
Cross slide rapid	m/min	6
Longitudinal rapid	m/min	8
Main inverter motor	HP	15KW (20HP) / 22KW (30HP)(opt)
Interver (Yaskawa)	HP	15KW (20HP) / 22KW (30HP)(opt)
Cutting fluid coolant pump	HP	1/8
Overall length	mm(inch)	3000/3500/4000/5000/6000 (118/138/157/197/236)
Overall width	mm(inch)	2200 (87)
Overall height	mm(inch)	2200 (87)
Net weight	kgs	2500/3000/3500/4000/4500
Gross weight	kgs	2800/3400/4000/4600/5150

* The above specifications subject to change without prior notice.
