Long Lifespan
Use pulsed fiber laser source, lifespan up to 100,000 hours.
High Working Efficiency
High speed digital galvanometer, repeatability accuracy 0.01mm, assembly line coding speed up to 100m.
Low Power Consumption
Air cooling, no consumables, low running cost.
Stable System
Original JCZ control board, windows system.
Multi Functions
Optional function: rotary, 3D curving, 3D large area, conveyor, auto focusing, automation, super long text, CCD camera etc.
Multi Results
Black marking, white marking, color marking for SS, deep engraving etc.
Use high speed swing motor(CTI motor & driver optional),
support assembly line, flying marking speed up to 100m/min.
Field Lens
Quartz made F-Theta lens, lifespan up to 5 years,
make sure high quality uniform facula distribution
Smooth lifting, small lifting error,
high mechanical strength,
strong and durable.
Fiber Laser Source
Each laser been tested for 8 hours of continuous light output, obtain stable performance for long term work.
Safety Socket
Aerial plug, easy & quick connection,
low impedance, precise signal output.
Lifting Axis
Linear guide rail, ball screw,
adjust focus accurately,
electrical up and down optional.
Standard Design Cabinet
Ergonomic design,
Workbench
Aluminum alloy workbench, hole spacing 25/50mm, with right angle positioning bar,
2D workbench optional, easy to adjust marking position.
Marking Control System
JCZ marking control system,
easy operation,
secondary development available.
Suitable for metals and various types of non-metal materials; alloy, oxide, coating, electroplate, ABS, Epoxy, engineering plastic, etc.
