Long Lifespan
Use pulsed fiber laser source, lifespan up to 100,000 hours.
High Working Efficiency
High speed digital galvanometer, repeatability accuracy 0.01mm, assembly line coding speed up to 100m.
Low Power Consumption
Air cooling, no consumables, low running cost.
Stable System
Original JCZ control board, windows system.
Multi Functions
Optional function: rotary, 3D curving, 3D large area, conveyor, auto focusing, automation, super long text, CCD camera etc.
Multi Results
Black marking, white marking, color marking for SS, deep engraving etc.
Digital Galvanometer
Use high speed swing motor(CTI motor & driver optional),
support assembly line, flying marking speed up to 100m/min
Field Lens
Quartz made F-Theta lens, lifespan up to 5 years,
make sure high quality uniform facula distribution.
Handheld Design
The hand-held marking head and one-touch marking button can be operated with one hand, aiming at the marking material for rapid positioning and rapid marking.
Fiber Laser Source
Aerial plug, easy & quick connection,
low impedance, precise signal output.
Precise & Fast Marking
The hand-held marking and focal length positioning frame enable one-hand marking operation easily.
Silver-plated contacts, corrosion-resistant,
temperature-resistant, flame-retardant, long life.
Lifting Workbench
Aluminum alloy workbench, durable,
multiple holes for easy adjustment of focus on different products.
Marking Control System
JCZ marking control system,
easy operation,
secondary development available
Suitable for metals and various types of non-metal materials; alloy, oxide, coating, electroplate, ABS, Epoxy, engineering plastic, etc.
