Capacity 90° (mm)
Round
Ø 400
Square
400 X 400
Rectangle
400 X 480
Capacity 45° (mm)
Ø 330
290 X 290
220 X 320
Bundle Cutting
MAX
MİN
Ø 210
Ø 170
210 X 210
170 X 170
210 X 340
170 X 10
190 X 190
Main Motor
1,5 kW / 300 Nm
Hydraulic Motor
0,18 kW
Coolant Motor
0,12 kW
Feeding Motor
0,37 kW
Conveyor Motor
Blade Size
3660 X 27 X 0,9 mm
Feeding Height
766 mm
Vice Maximum Opening
355 mm
Vice Maximum Closing
Sıfır Zero
Vice Height
170 mm
Rolled Table Width
370 mm
Height-Width-Length
1350 X 1500 X 2200 mm
Weight
1000 kg
