Isitan KM-12 Arm Guillotine Shear (KM -12)

Built according to EC Safety Directives and has CE Mark
Steel constructed body and frame
Large table facility the command of sheet metal by operator
Cutting lever made of plate steel for the purposes of flexibility and stability
Mechanical pressure system prevents sliding of sheet during
Double Gear-rack system for easy adjustment of Back-gauge
Front set appropriate for angle sheet metal cutting

MODEL	KM -12
Table dimension	600x1270	mm
Blade length	1050	mm
Shearing Length	1030	mm
Shearing capacity (mild steel)	1.5	mm
Back gauge length	500	mm
Length	1850	mm
Width	1100	mm
Height	1200	mm
Weight	500	kg
