Model
1350 – R.P.
Machine name
1350 mm Roll ve Piyano Baskılı Kombi Üniteli
Kalibre Zımpara Makinası
Machine working width
(mm)
0 – 1350
Material processing thickness
3 – 120
Sandpaper sizes
(2x) 1350*2620
Conveyor system features
speed adjustable system,
wear resistant conveyor belt,
*table movable
Unit 1 Features
Ünite type
Roll Unit
Front drum diameter and feature
Ø180, rubber coated drum,
Rubber hardness 65-70 sh.
Motor power
(kW)
15
Sanding cutting speed
(m/s)
18
Engine braking system
Yes
Unit 2 Features
Unit type
Piano Printed Combi Unit
Number of piano prints
22
Ø150, rubber coated front drum,
Rubber hardness 65-70 shor
Electric panel
Siemens / Mitsubishi
Machine color
Ral 7035 - 5010
Oscillation in units
Cover safety switch
Engine protection unit
*The table is movable: The thickness adjustment according to the material to be processed in the machine is made by moving the conveyor belt up / down.
*Body moving: While the machine conveyor is fixed in this system, the thickness adjustments are provided by the body movement. It is offered optionally.
**3 - 120 : Vacuum must be added to the conveyor system for parts with thicknesses less than 3 mm. It is offered optionally.
