Electric Panel
ELECTRIC PANEL
The control panel is the equipment mounted on and moving with the bridge.
ELECTRIC PANEL / PLATFORM
The control panel has a mobile design and can move independent of the bridge.
Power Supply Unit
POWERMAX POWER SUPPLY UNIT
Cost-effective single gas (air or nitrogen) cutting systems for pipe cutting, angled cutting and robot 3D cutting. Power options are available in the 45 - 125 Amp range.
MAX PRO 200 POWER SUPPLY UNIT
MaxPro 200 plasma cutting systems are designed for high-tonnage and high-capacity applications.
Safety
LIGHT BODYGUARD
Leuze M 4000 backlight protection curtain that complies with CE standards, ensuring safe operation.
BODYGUARD CAAF
With the cage barrier system built around the machine, external access to the moving parts of the machine is prevented.
EMERGANCY STOP CABLE AROUND THE GANTRY
Thanks to the security cable around the bridge, the machine can be stopped when the cable is pulled by the operator or someone around in case of an undesired condition.
Cutting Station
ERMAK THC
Optimal consumable life and superior cut quality with arc voltage sampling and control
Cutting Station
IHT M4000 CAP
Provides automatic gap control for oxygen cutting machines.
Air conditioning
ELECTRIC PANEL COOLER
Coolers or heaters can be installed on the electrical panel according to operation environment.
Controller
HYPERTHERM EDGECONNECT TC CONTROLLER
EDGE® Connect, Hypertherm's latest Computer Numerical Control (CNC) platform, provides unrivalled reliability, powerful embedded capabilities, and a high level of customization.
Machine Options
I-CUT PLATE
Offers an optimum solution for all your needs with its advanced precision cutting quality, production line, and automation compatibility.
Marking Pen
MARKING PEN
As a pneumatic system, it can be used to draw figures or write with hard-tipped dot strokes on flat surfaces with dot strokes.
Motor
MITSUBISHI DIGITAL AC SERVO MOTOR
A double-driven synchronous motor, and a single-driven AC servo motor in accordance with CE and CSA standards are used on Y and X axes, respectively.
Oxygen Cutting
OXY CUT
Oxygen cutting machine is suitable for heavy duty and general use in medium and higher thickness. It allows users to perfectly cut sheet metals up to 300 mm depending on the user's demands. Users of Pronest advanced nesting software supplied with the machine will benefit from the feature of programming more than one cutting process.
Oxygen Cutting
OXY CUT ±45° MANUAL ANGLE CUTTING APPARATUS
Oxygen cutting torch is a manual system that allows cutting with a maximum of ±45 degrees in horizontal and vertical direction, depending on the manual angle apparatus.
Plasma Gas Console
AUTOMATIC GAS CONSOLE
Controls all plasma system settings from the CNC.
Plasma Manual Angle Apparatus
EXPANDED BRIDGE MANUAL ± 45° ANGLE CUTTING APPARATUS
When a manual angle apparatus is attached to the plasma or oxygen cutting torch in the extended bridge machine, the machine bridge can be extended and the machine length can be increased.
Plasma Manual Angle Apparatus
STANDARD BRIDGE MANUAL ± 45° ANGLE CUTTING APPARATUS
When a manual angle apparatus is attached to the plasma or oxygen cutting torch in the standard bridge machine, full distance full length cutting losses are experienced due to the angled stance of the torch.
Plasma Feature
POINT LASER LIGHT FEATURE
Thanks to the laser light, it allows us to see more clearly where the torch is.
AUTOMATIC CUTTING HEIGHT CORRECTION SOFTWARE
Automatically detects and corrects arc voltage changes during plasma cutting.
PLATE ALIGNMENT FEATURE
It is the feature that allows the workpiece or plate placed arbitrarily on the cutting table to be aligned by reference from two corners by meanss of a torch or a laser light.
Reducer
NEUGART PLANET TYPE REDUCER
High acceleration levels are achieved thanks to the servo motor, driver, and reducer with high precision reaction times.
Sheet Cutting Software
PRONEST (BRIDGE CUT) SOFTWARE
In plasma cutting, it starts to cut the other piece's inlet before chain cut blasting.
Sheet Cutting Software
PRONEST (CHAIN CUT) SOFTWARE
In oxygen cutting, it starts to cut the other piece's inlet before chain cut piercing.
PRONEST (COMMON CUT) SOFTWARE
Ensures a single cut by joining the outer contours of the pieces.
Plasma Manual Angle Apparatus
STANDARD BRIDGE MANUAL ± 45° ANGLE CUTTING APPARATUS
When a manual angle apparatus is attached to the plasma or oxygen cutting torch in the standard bridge machine, full distance full length cutting losses are experienced due to the angled stance of the torch.
