Bevel Cutting:
Makes 3D angled cuts possible. It can cut up to ±45° angle. Easy wiring and assembly. 360° rotation capability.
Thanks to its motor-controlled biaxial cutting head, it can move +- 45 degrees.
Smart Features:
Different types of nozzles with different diameters must be used before cutting materials of different types and thickness.
An automatic profile alignment system has been developed for precise profile cutting with a profile cutting table in machines with Fibermak pipe and profile cutting options.
An automatic profile alignment system has been developed for precise profile cutting with a profile cutting table in machines with Fibermak pipe and profile cutting options.
Controller:
With its proven industrial PC-based control technology, Beckhoff offers a wide range of products for different applications.
Software:
It facilitates 3D CAD/CAM design and cutting of standard profiles, including square or round pipes.
Lantek Flex3d Tubes is a CAD/CAM software system for designing, nesting and cutting pipes and pipe pieces.
Programming with Lantek Inside is as easy as using your smartphone. The operator can easily design the program and initiate the cutting process.
Resonator:
State-of-the-art fibre laser resonators produced in Ermaksan Optoelectronics centre stand out with their power classes ranging from 1 to 15 kW, high beam quality, and advanced control features.
Being customized according to customer needs and requests, IPG-YLR Series (Cassette type) resonators offer affordable solutions to their users. Power alternatives between 1 to 4 kW are available.
IPG-YLS Series (Cabin type) resonators, which are provided according to customer needs and requests, have significant advantages thanks to the quality of easy and on-site maintenance. Power options from 1 to 20 kW are available.
Cooling System:
Provides cooling of the relevant parts for continuity and precision in cutting.
Cutting Head:
With its higher focal length and replaceable Spot Size feature, Procutter enables fast cutting on thin materials and high quality cuts on thick materials.
LightCutter is an ideal and economical solution for all laser cutting applications in the low to medium power range up to 4 kW.
The intended use of PierceTec is to confirrm that the first piercing is completed and to allow the machine to start cutting without waiting for the piercing time set from the CNC. This feature saves time and increases efficiency.
Handwheel:
It is an equipment that facilitates the positioning of the head even without staying by the control panel.
Provides wireless and manual axis movements for quick positioning of the cutting head.
Acceleration:
The 2.5 G acceleration capability of the Fibermak Momentum series with servo motors significantly increases the efficiency of transitions between pieces.
Thanks to the 4G high acceleration in the Fibermak Momentum series with servo motors, which offers big advantages in transitions between pieces, production time is reduced and productivity is increased by an average of 15% per hour.
Pipe Cutting Unit:
In addition to flat sheet metal cutting, we also allow our users to benefit from optional pipe and profile cutting features in our Fibermak Momentum series machines.
Cutting Table:
-
DOUBLE AUTOMATIC SHUTTLE TABLE
It consists of two movable tables.
-
PNEUMATIC SHUTTLE TABLE WITH TRANSFER BALLS
Thanks to this system, the sheet metals placed on the table can be easily moved by the operator. It especially prevents the stainless steel sheets from scratches while being placed on the grill.
It is an automatic profile alignment system for precise profile cutting with profile cutting table.
Covered Shuttle Table:
Conveyor:
This is a belt system that transfers the pieces and slags falling from the grills to the collection chamber after the cutting process.
Dry Air System:
Proportional Valve System:
This is the system that automatically adjusts the O2 or N2 auxiliary gas according to the material type, and the auxiliary gas pressure according to the material thickness, and transfers the gas to the cutting head.
Filtering System:
-
FILTERING UNIT
Ensures cleaning of smoke and small particles formed during cutting via suction.
-
EXHAUST FAN
The suction fan sucks the smoke and particles inside and discharges them to another area. Thus, the harmful particles in the air within the working environment are removed.
Safety Equipment:
Lubrication System:
-
CENTRAL LUBRICATING SYSTEM
Automatic lubrication of the parts that require lubrication for extended lifetime of the machine by central lubrication system, without the need for an operator.
Automation System:
Sheet Metal Loading System:
Fully automatic sheet metal loading and unloading system.
- VACUMASTER SHEET METAL LOADING SYSTEM
The semi-automatic jib crane type vacuum loading system manufactured by ERMAKSAN provides great convenience to its users by allowing the raw material to be loaded easily and automatically on the shuttle table precisely and properly. It is a practical and affordable solution for mass production
