Angle Gauge
DATA-M LASER PROTRACTOR
Developed by Data M Engineering, it is a powerful solution for measuring bending angles in press brakes.
IRIS PLUS LASER PROTRACTOR
Automatic angle measurement and automatic correction of bending angle
KEBA DIGITAL ANGLE GAUGE
With KEBA angle measuring systems, complex bends can be performed extremely easily and with maximum accuracy.
Backgauge
4-AXIS BACKGAUGE
Backgauge with 4-axis (X, R, Z1, Z2) servo motor allows you to obtain precise bending of the backgauge with 0.05 mm positioning accuracy according to the desired geometry.
5-AXIS BACKGAUGE
Backgauge with 5-axis (X, R, Z1, Z2, X5) servo motor allows you to obtain precise bending of the backgauge with 0.05 mm positioning accuracy according to the desired geometry. One of the backgauge latches moves within ±100 mm and enables conical bending.
6-AXIS BACKGAUGE ATF TYPE
ATF type backgauge system with 6-axis servo motor is automatically positioned for optimum bending results.
Rear Support
PNEUMATIC REAR SUPPORTS
This is the latch group that is additionally mounted for easy bending in the machine and can also operate pneumatically apart from the backgauge.
Back Protection
LEUZE MLC510 BACK PROTECTION
The back protection light barrier stops the machine in case an object enters the rear of the machine during operation and ensures safety.
REARGUARD+SWITCH
Maximizes your safety thanks to the rear sliding cage and the switch.
MOTORIZED SHUTTER DOOR REAR COVER
A rear safety door that can be used with motors and manually, and has aluminium partitions, which are provided in anthracite grey and metallic grey colours.
Foot Pedal
DOUBLE FOOT PEDAL
Double foot control pedal designed to ensure easy bending.
Barcode Reader
BARCODE READER
Facilitates the operator's intensive and complex work processes and prevents errors.
Bending Line
LASER BEND LINE - B-LIGHT 02
This is a system utilized for bending without the use of backgauge with the help of laser beam, and that allows the bending axis to be clearly visible.
LASER BENDING LINE - ROLLERI B-LIGHT 01
This is a system utilized for bending without the use of Backgauge with the help of laser beam, and that allows the bending axis to be clearly visible.
Ruler
RULER ON TOP BEAM
You can get precise results with Y1+Y2 axis synchronization with a tolerance of 0.01 provided by linear rulers.
Controller
DELEM DA-66T
The 2D touchscreen display controller is your best assistant in the most difficult bending operations with its functional features.
DELEM DA-69T
DA-Touch series, 3D graphic display controller is always by your side to ensure the most precise bending operations with its powerful features.
ER 99 PLUS
It is possible to export calculated flat patterns in DXF format. Tools and parts can be imported as CAD files.
Pendant Arm
STANDARD CONTROLLER ARM
This is the standard equipment in which the CNC controller, which is required for the machine to work, is mounted and allows the controller to move to the front or back of the machine when required.
ERGONOMIC CONTROLLER ARM
HEIGHT ADJUSTABLE CNC PENDANT ARM
The height-adjustable CNC pendant arm with shock absorber stands out with its modern design and functional features.
Led Bar Guiding System
LED BAR GUIDING SYSTEM
Shows the location of the bent pieces and bending stations with coloured LED bars.
Front Support Arms
FRONT SLIDING ARMS
Sliding front support arms with stopper, metric system scales and height adjustment feature allows more precise and easier bending operations.
AP3-AP4 FRONT SUPPORT ARMS SYSTEM
The sheet support system used where the plinth rates of the elastic fine sheets to be bended are bigger.
Front Protection
SIDE CAGE+SWITCH+LASERSAFE IRIS
The system, which is also used as a front finger protection, stops the movement of the upper beam when an object is detected.
SIDE CAGE+SWITCH+LASERSAFE IRIS PLUS
This is a system that can measure the angle and automatically make angle correction to the CNC.
SIDE CAGE+SWITCH+LASERSAFE
The system, which is also used as a front finger protection, stops the movement of the upper jaw when it detects any object.
Robot Interface
ROBOT INTERFACE
Robotic automation solutions provide advantages in terms of efficiency, quality, speed, performance, cost, and safety.
Start-Stop
START-STOP
This is the optional system that stops the main motor when there is no upper beam movement in the machine within 2 minutes.
START-STOP + SOFT STARTER
This is the STAR - TRIANGLE motor speed change that we use as an option. Ensures safer and easier speed change for the motor.
