Angle Gauge
DATA-M LASER PROTRACTOR
Developed by Data M Engineering, it is a powerful solution for measuring bending angles in press brakes.
IRIS PLUS LASER PROTRACTOR
Automatic angle measurement and automatic correction of bending angle
KEBA DIGITAL ANGLE GAUGE
With KEBA angle measuring systems, complex bends can be performed extremely easily and with maximum accuracy.
Backgauge
SINGLE-AXIS BACKGAUGE
Backgauge single-axis (X) asynchronous motor and 0.05 mm positioning accuracy according to the desired geometry
2-AXIS BACKGAUGE
Backgauge with 2-axis (X, R) servo motor allows you to obtain precise bending of the backgauge with 0.05 mm positioning accuracy according to the desired geometry.
Rear Support
PNEUMATIC REAR SUPPORTS
This is the latch group that is additionally mounted for easy bending in the machine and can also operate pneumatically apart from the backgauge.
Back Protection
LEUZE MLC510 BACK PROTECTION
The back protection light barrier stops the machine in case an object enters the rear of the machine during operation and ensures safety.
REARGUARD+SWITCH
Ruler
RULER ON TOP BEAM
You can get precise results with Y1+Y2 axis synchronization with a tolerance of 0.01 provided by linear rulers.
Maximizes your safety thanks to the rear sliding cage and the switch.
MOTORIZED SHUTTER DOOR REAR COVER
A rear safety door that can be used with motors and manually, and has aluminium partitions, which are provided in anthracite grey and metallic grey colours.
Foot Pedal
DOUBLE FOOT PEDAL
Double foot control pedal designed to ensure easy bending.
Barcode Reader
BARCODE READER
Facilitates the operator's intensive and complex work processes and prevents errors.
Throat Depth
410 MM THROAT DEPTH
410 mm throat depth is standard.
Crowning System
MANUAL CROWNING SYSTEM
The ideal deflection balance can be achieved with the manual crowning system that operates by manually turning the hand wheel.
MOTORISED CROWNING SYSTEM
Thanks to the CNCcontrolled motorized crowning system, the ideal deflection balance can be achieved with the motor.
Bending Line
LASER BEND LINE - B-LIGHT 02
This is a system utilized for bending without the use of backgauge with the help of laser beam, and that allows the bending axis to be clearly visible.
LASER BENDING LINE - ROLLERI B-LIGHT 01
This is a system utilized for bending without the use of Backgauge with the help of laser beam, and that allows the bending axis to be clearly visible.
Ruler
RULER ON TOP BEAM
You can get precise results with Y1+Y2 axis synchronization with a tolerance of 0.01 provided by linear rulers.
Extraction System
SHEET EXTRACTION SYSTEM
This is the system that helps the bent products to be removed from the table of the press brake and transferred to the next stage.
Hydraulic System
HAWE HYDRAULIC SYSTEM
This system ensures that sufficient amount of oil required for the main rollers, pressing rollers, and feeler adjustment rollers circulates in the system at an accurate pressure.
Tool Storage Cabinet
TOOL STORAGE CABINET
This is a cabinet manufactured by Ermaksan to protect the upper and lower dies used in our machine from external impact, and to keep them clean.
ROLLERI TOOL CABINET
This is a cabinet manufactured by Rolleri to protect the upper and lower dies in our machine from external impact, and to keep them clean.
Controller
ESA S640
The 2D programmable CNC controller can support up to 6 axes.
Controller
ESA S660W
2D programmable CNC press brake controller. Can control up to 12 axes. Capable of 3D imaging.
Controller
ESA S675
2D programmable CNC press brake controller. Can control up to 12 axes. Capable of 3D imaging.
Pendant Arm
STANDARD CONTROLLER ARM
This is the standard equipment in which the CNC controller, which is required for the machine to work, is mounted and allows the controller to move to the front or back of the machine when required.
ERGONOMIC CONTROLLER ARM
HEIGHT ADJUSTABLE CNC PENDANT ARM
The height-adjustable CNC pendant arm with shock absorber stands out with its modern design and functional features.
Led Bar Guiding System
LED BAR GUIDING SYSTEM
Shows the location of the bent pieces and bending stations with coloured LED bars.
WILA SMART TOOL LOCATOR
This system determines the order of use of the partial dies, which are mounted on the upper beam in full length, and attached to the top tool holder, by means of laser beam.
Front Support Arms
FIXED FRONT SUPPORT ARMS
Helps the operator by acting as a stand for the bent sheet metal in machines working with standard front safety system.
FRONT SLIDING ARMS
Sliding front support arms with stopper, metric system scales and height adjustment feature allows more precise and easier bending operations.
Front Protection
SIDE CAGE+SWITCH+AKASII
AKAS finger protection stops the movement of the upper beam when an object is detected.
SIDE CAGE+SWITCH+DSP AP MCS
DSP MCS AP stops the movement of the upper beam when an object is detected. The beam continues to move if the object is removed.
SIDE CAGE+SWITCH+LEUZE
If the brackets used as front light protection detect an object in the beam movement, they stop the movement of the beam; if the beam is removed, the beam keeps moving at the same speed. However; if the object remains in between, the beam keeps moving at a low (manual) speed.
Robot Interface
ROBOT INTERFACE
Robotic automation solutions provide advantages in terms of efficiency, quality, speed, performance, cost, and safety.
Start-Stop
START-STOP
This is the optional system that stops the main motor when there is no upper beam movement in the machine within 2 minutes.
START-STOP + SOFT STARTER
This is the STAR - TRIANGLE motor speed change that we use as an option. Ensures safer and easier speed change for the motor.
Lubrication System
CENTRAL LUBRICATING SYSTEM
Automatic lubrication of the parts that require lubrication for extended lifetime of the machine by central lubrication system, without the need for an operator.
