Foot Pedal
FOOT PEDAL SUITABLE FOR SINGLE AND MASS CUTTING
This movable pedal allows to start and finish cutting operation easily anywhere in the cutting area, and to easily stop the operation when desired.
Blade
ERMAKSAN BLADE
You can prefer this affordable blade for black and soft sheet metal cutting.
STAINLESS BLADE
Extends the dulling time of the blade while providing a more precise cut for a longer period of time in stainless and black sheet cutting.
Throat
350 MM
Allows cutting sheets longer than the cutting length with a standard throat depth of 350 mm.
WITHOUT THROAT
Customers who will not perform splitting on sheet metals can prefer this option to lower the costs.
Electrical System
SIEMENS ELECTRICAL SYSTEM
Electrical equipment such as the components that make up the motor power circuit, contactor, motor protection, and main switch are offered with proven Siemens quality.
T-square
1000 MM FRONT T-SQUARE
It is your best assistant that facilitates the continuous 90° cutting of the sheets.
ANGLE ADJUSTED T-SQUARE
Allows high precision, easy cutting in angled cutting thanks to angle adjusted T-square.
Hydraulic System
HAWE HYDRAULIC SYSTEM
This system ensures that sufficient amount of oil required for the main rollers, pressing rollers, and feeler adjustment rollers circulates in the system at an accurate pressure.
Cutting Line
CUTTING LINE ILLUMINATION SHADE WIRE
Generates projection over sheet metal to be cut to provide high quality and precise cutting.
LASER CUTTING LINE
Thanks to laser cutting line, angled and lined cutting can be easily controlled.
Controller
CYBTOUCH 8 G
Touch screen with high contrast and vivid colours.
DELEM DAC 360T
4.7” monochrome bright LCD display.
ESA S630
The controller can support up to 4 axes and has a 2D graphic display.
Anti-Twist
ANTI-TWIST SYSTEM
Anti-twist system keeps the material being cut stable during top blade moves, and prevents twisting while cutting thin and strip-shaped sheet metals.
Backgauge
1000MM ERMAKSAN MOTORIZED BACKGAUGE
With an accuracy of 0.1 mm, the 1 meter long fast backgauge provides precise cutting results. With the automatic folding function for your sheets longer than 1 m, it allows you to freely operate.
Back Protection
LEUZE MLD 520
Prevents undesired accidents by creating an invisible light barrier behind the machine.
Front Support Arms
1000 SIDE T-SQUARE AND FRONT SUPPORT ARMS
While the front arm with t-square allows you to slide the sheet metal 90 degrees (perpendicular) to the machine, the support arms make it easier to work and slide sheet metals, allowing you to make more precise and faster cuts.
Front Protection
FRONT VISOR
Complying with international safety standards, the finger protection provides a safer working environment.
LASER LIGHT FINGER PROTECTION
Allows the cutting area to be observed better and more easily, allowing the operator to intervene the sheet metal to be cut more easily.
Sheet Metal Support System
SOLID SHEET METAL SUPPORT SYSTEM
Solid table-type pneumatic sheet metal support system prevents sagging of wide and thin sheet metal to enable more precise cutting
Sheet Metal Support System
RTS
This system allows to retract the cut sheet metal automatically from the front part of the shear for performing several operations on the same sheet metal within minimum time.
Sheet Metal Support System
X-TYPE PNEUMATIC SHEET METAL SUPPORT SYSTEM + RTS
More precise cuts are achieved with pneumatic X type levers which prevent sagging of wide and thin sheet metals.
Sheet Metal Sliding
FRONT SHEET METAL SLIDING GROUP WITH BALLS
Front sheet metal sliding system with balls enables faster cutting by simplifying operation and sheet metal sliding
MOTORIZED SHEET METAL SLIDING SYSTEM
After the sheet metal to be cut with shear is placed for the cutting process, cutting process takes place after an automatic system slides the sheet metal, instead of an operator.
WITH T GROOVE AND RULER
T-grooved worktable with static and dynamic rigidity ensures precise cuts and ease of use.
Feeler Adjustment System
AUTOMATIC FEELER ADJUSTMENT SYSTEM
The automatic feeler adjustment system, which does not require separate adjustments for sheet metals with different thickness, adjusts the gaps between the blades.
Oil Heating and Cooling System
OIL HEATING AND COOLING SYSTEM
In the environments where the operating temperature is inconvenient, hydraulic oil is heated up to the desired temperature and it is ensured that the shear operates in the optimum environment.
Lubrication System
CENTRAL LUBRICATING SYSTEM
Automatic lubrication of the parts that require lubrication for extended lifetime of the machine by central lubrication system, without the need for an operator.
