Angle Gauge
DATA-M LASER PROTRACTOR
Developed by Data M Engineering, it is a powerful solution for measuring bending angles in press brakes.
IRIS PLUS LASER PROTRACTOR
Automatic angle measurement and automatic correction of bending angle
KEBA DIGITAL ANGLE GAUGE
With KEBA angle measuring systems, complex bends can be performed extremely easily and with maximum accuracy.
Backgauge
4-AXIS BACKGAUGE
Backgauge with 4-axis (X, R, Z1, Z2) servo motor allows you to obtain precise bending of the backgauge with 0.05 mm positioning accuracy according to the desired geometry.
5-AXIS BACKGAUGE
Backgauge with 5-axis (X, R, Z1, Z2, X5) servo motor allows you to obtain precise bending of the backgauge with 0.05 mm positioning accuracy according to the desired geometry. One of the backgauge latches moves within ±100 mm and enables conical bending.
6-AXIS BACKGAUGE ATF TYPE
ATF type backgauge system with 6-axis servo motor is automatically positioned for optimum bending results.
Rear Support
PNEUMATIC REAR SUPPORTS
This is the latch group that is additionally mounted for easy bending in the machine and can also operate pneumatically apart from the backgauge.
Back Protection
REARGUARD+SWITCH
Maximizes your safety thanks to the rear sliding cage and the switch.
LEUZE MLC510 BACK PROTECTION
The back protection light barrier stops the machine in case an object enters the rear of the machine during operation and ensures safety.
MOTORIZED SHUTTER DOOR REAR COVER
A rear safety door that can be used with motors and manually, and has aluminium partitions, which are provided in anthracite grey and metallic grey colours.
Foot Pedal
DOUBLE FOOT PEDAL
Double foot control pedal designed to ensure easy bending.
Barcode Reader
BARCODE READER
Facilitates the operator's intensive and complex work processes and prevents errors.
Throat Depth
410 MM THROAT DEPTH
410 mm throat depth is standard.
510 MM AND ABOVE THROAT DEPTH
Special throat depths up to 1500 mm are offered for wider bending.
Crowning System
HYDRAULIC CROWNING SYSTEM
Thanks to the CNC-controlled hydraulic crowning system, with multiple hydraulic cylinders, it is possible to achieve the ideal deflection balance by means of the force applied to the special lower beam.
HYDRO-MECHANICAL RIDGING
Thanks to the CNC-controlled hydro-mechanical crowning system, it is possible to achieve the ideal deflection balance with a hydraulic cylinder.
MANUAL CROWNING SYSTEM
The ideal deflection balance can be achieved with the manual crowning system that operates by manually turning the hand wheel.
Bending Line
LASER BEND LINE - B-LIGHT 02
This is a system utilized for bending without the use of backgauge with the help of laser beam, and that allows the bending axis to be clearly visible.
LASER BENDING LINE - ROLLERI B-LIGHT 01
This is a system utilized for bending without the use of Backgauge with the help of laser beam, and that allows the bending axis to be clearly visible.
Ruler
RULER ON TOP BEAM
You can get precise results with Y1+Y2 axis synchronization with a tolerance of 0.01 provided by linear rulers.
Seater
INDUSTRIAL TYPE SEATER
Provided exclusively together with the machines where the operators sit while working, taking ergonomics in the industrial environments into consideration, this chair allows the operator to work comfortably.
With Knee Gap
WITH KNEE GAP
Allows the operator to sit while working in order to quickly and comfortably bend the pieces with small dimensions and produced with mass production.
Electric Panel Heating - Cooling
ELECTRIC PANEL HEATING AND COOLING SYSTEM
An optional electric panel with heating and cooling system, manufactured in accordance with CE standards is provided.
Hydraulic System
HAWE HYDRAULIC SYSTEM
This system ensures that sufficient amount of oil required for the main rollers, pressing rollers, and feeler adjustment rollers circulates in the system at an accurate pressure.
Tool Storage Cabinet
TOOL STORAGE CABINET
This is a cabinet manufactured by Ermaksan to protect the upper and lower dies used in our machine from external impact, and to keep them clean.
ROLLERI TOOL CABINET
This is a cabinet manufactured by Rolleri to protect the upper and lower dies in our machine from external impact, and to keep them clean.
Controller
CYBELEC VISITOUCH 19 MX
Features a 19” modern aerodynamic glass surface full touchscreen display. Has a compact structure with the CNC board mounted on the back of the display.
DELEM DA-53T
2D graphic CNC controller. Supports up to 4 axes. The display size is smaller (10.1") than DA 58 T.
DELEM DA-58T
2D graphic CNC controller. Supports up to 4 axes. The display size is larger (15") than DA 53 T.
Pendant Arm
STANDARD CONTROLLER ARM
This is the standard equipment in which the CNC controller, which is required for the machine to work, is mounted and allows the controller to move to the front or back of the machine when required.
ERGONOMIC CONTROLLER ARM
HEIGHT ADJUSTABLE CNC PENDANT ARM
The height-adjustable CNC pendant arm with shock absorber stands out with its modern design and functional features.
Led Bar Guiding System
LED BAR GUIDING SYSTEM
Shows the location of the bent pieces and bending stations with coloured LED bars.
WILA SMART TOOL LOCATOR
This system determines the order of use of the partial dies, which are mounted on the upper beam in full length, and attached to the top tool holder, by means of laser beam.
Front Support Arms
FIXED FRONT SUPPORT ARMS
Helps the operator by acting as a stand for the bent sheet metal in machines working with standard front safety system.
AP3-AP4 FRONT SUPPORT ARMS SYSTEM
The sheet support system used where the plinth rates of the elastic fine sheets to be bended are bigger.
FRONT SLIDING ARMS
Sliding front support arms with stopper, metric system scales and height adjustment feature allows more precise and easier bending operations.
Front Protection
SIDE CAGE+SWITCH+LASERSAFE IRIS PLUS
This is a system that can measure the angle and automatically make angle correction to the CNC.
SIDE CAGE+SWITCH+LASERSAFE
The system, which is also used as a front finger protection, stops the movement of the upper jaw when it detects any object.
SIDE CAGE+SWITCH+LEUZE
If the brackets used as front light protection detect an object in the beam movement, they stop the movement of the beam; if the beam is removed, the beam keeps moving at the same speed. However; if the object remains in between, the beam keeps moving at a low (manual) speed.
Robot Interface
ROBOT INTERFACE
Robotic automation solutions provide advantages in terms of efficiency, quality, speed, performance, cost, and safety.
Start-Stop
START-STOP
This is the optional system that stops the main motor when there is no upper beam movement in the machine within 2 minutes.
START-STOP + SOFT STARTER
This is the STAR - TRIANGLE motor speed change that we use as an option. Ensures safer and easier speed change for the motor.
Lubrication System
CENTRAL LUBRICATING SYSTEM
Automatic lubrication of the parts that require lubrication for extended lifetime of the machine by central lubrication system, without the need for an operator.
