Ercolina GB250 Mandrel Benders (GB250)

Brand : Ercolina

Stock Amount : 1

Notify me when the price goes down

Notify me when it is in stock

The GB250 is the largest machine in the GB line, with interactive PLC with touch screen guaranteeing simple accessibility to manual and automatic operating modes; integrated system diagnostics and multilingual operator interface.

Maximum Material Length 6 mt
Programmable bending angle from 0° to 195°
YBC & XYZ Programming
Springback setting adjustment on each bend
USB port for unlimited saving of programs and information
Quick tool change system for increased productivity
Ercolina patented KST tube clamping system
Interactive PLC with touch screen ensures easy accessibility to manual and automatic operation modes; integrated system diagnostics and multilingual operator interface
Remote control by hand
Importing .iges .dxf .Iges Tekla files (optional)
Wi-fi

Flexion modulus	425 cm³
Minimum external diameter	10 mm
Maximum outer diameter	280 mm
Maximum Bend Radius (CLR)	650 mm
Minimum Bend Radius (CLR) 100	100 mm
Maximum bend angle	195 °
Installed power	60 kW
Programs	Limitless
Bend speed	4,9° /s
Tank capacity	500 lt. hydraulic oil
Noise level	63 dB
Dimensions (Length x Width x Height)	9636 x 4406 x 2400 mm
Weight	35250 kg
