Bochi VMC650H Machining Center (VMC650H)

High rigidity, high accuracy, high speed, high efficiency, high reliability and large torque. They have a wide working range.
These machines are used in automotive, motorcycle, manufacturing, sewing machine, motor and instrument industries for milling, drilling, counterboring, boring, tapping and countersinking valve-type, cam, dies/molds and plate/disk type workpieces. They are especially suitable for all sorts of complex 2D/3D convex/concave molds and complex ID/OD surfaces. They can be used for medium/small batch multi-work production or be linked into an auto line for large batch production.
Using these machines can save manufacturing equipment, shorten production cycle, guarantee machining accuracy and increase productivity.
VMC650：Rectangular hardened sliding guideways of 3-axes.
VMC650L：Linear guideways are used in X and Y axes while rectangular hardened sliding guideways in Z-axes.
VMC650H：Linear roller ways and silence lead screws from famous makers are used for X, Y and Z axes.

Spec.		Unit	VMC650H
Work table	Dim. of table(W×L)	mm	500×800
	T-slot (num.-size × space)	mm	5-18×80
	Permissible load	kg	500
Spindle	Spindle taper hole	/	ISO 40
	Power of main motor (cont./15min overload)	kW	7.5/11
	Top speed of spindle	r/min	12000
Travel	X-axis right and left travel	mm	600
	Y-axis back and forth travel	mm	500
	Z-axis up and down travel	mm	600
	Distance of spindle nose to table face	mm	120-720
	Distance of spindle center to column way	mm	570
Feed	X/Y-axis rapid traverse	m/min	48
	Z-axis rapid traverse	m/min	48
	Max. cutting federate	mm/min	10000
Magazine	Capacity of magazine	pcs	24
	Max. tool weight	kg	8
Accuracy	Repeatability (JIS)	mm	±0.008
	Positioning accuracy (JIS)	mm	±0.003
Others	Air source	L/min	250
	Air pressure	MPa	0.6
	Gross weight of machine	kg	6000
	Net weight of machine	kg	5500
	Dimensions of machine (L×W×H)	mm	2800x2400x3050
