Say-Mak SHKM 65 Hydraulic Ironworker (SHKM 65)

Brand : Say-Mak

Price : 0,00 EURO(Vat included)

Stock Amount : 0

Delivery Time 45-60 Days After O.C.

Shipment Place Turkiye

Payment Terms % 50 T/T On O.C., % 50 T/T B.S.

Made In Turkiye

Min. Order Qty. 1 Pcs.

Warranty1 Year

Artır Azalt

2 Separate hydraulic piston and foot pedal to allow 2 operator to work at the same time
More productivity with adjustable piston stroke distance
Central lubrication system
Electrical back gauge
Five individual workstation on the machine:
Punch and die and standard punching tools
Steel solid round and square bar cutting blade set
Angle cutting blade set
Sheet metal cutting shear
U-Notching blade set

	PUNCHING	SHKM 65
	"Dimeter x max .Thickness"	Ø 26 x 20 mm
	Diameter x thickness	0 57 x 10 mm
	Maximum Diameter	Ø 110 x 3 mm
	Stroke	55 mm
	Stroke count in (20 mm)	x 25
	Throat depth	355 mm
	Working height	1030 mm
	STEEL BAR SHEAR	SHKM 65
	Raund/Square	Ø 45- 45 mm
	ANGLE SHEAR	SHKM 65
	Angle section (90°)	120 x 120 x 12 mm
	Angle section (45°)	70 x 10 mm
	Working height	1140 mm
	SHEET METAL SHEAR	SHKM 65
	Sheet metal	300 x 20 mm
	Sheet metal	375 x 15 mm
	Blade Length	380 mm
	Shearing with angle	100 x 15 mm
	Working height	900 mm
	NOTCHING	SHKM 65
	Thickness	10 mm
	Width	45 mm
	Depth	90 mm
	Working height	900 mm
	OPTIONAL TOOLS	SHKM 65
	"U-I Section blades (for UPN - IPN cutting)"	120 x 58 mm
	T Section Blades	90 x 11x" mm
	Special V-Notching Tooling	100 x 100 x 10 mm
	V- Bending Press Brake Bar Bend Max. Sheet Bend Max.	"250 x 15 mm 500 x 3 mm"
	Punching On Notcher Throat Depth Max. Capacity	"125 mm 0 38 x 8 mm"
